Lọc thứ cấp (Túi lọc - Hộp lọc - Lọc cho hệ thống ahu)
- Hộp lọc thứ cấp
- Túi lọc thứ cấp

Separator Standard Capacity Medium Filter



N.B.S. Testing 90% ~ 95%
80% ~ 85%
60% ~ 65%

Operating Conditions

  • Apply Temperature: 80°C
  • Apply Humidity: 100%RH (No Dew)
  • Separator air filter

Qualified With

  • Std. EN 1822 Class F5 / F6 / F7 / F8
  • Std. IES RP-CC-001.3 MERV 11 / 13 / 14



Specifications

Model Dimension Capacity Initial P.D. Final P.D.
Length * Width * Depth
Box
Type		 M9BA305610290 305×610×290 mm 26.8 CMM
(946 CFM)

95%:
14.0 mmH2O (137pa)

85%:
12.7 mmH2O (124pa)

65%:
8.9 mmH2O (88pa)

95%:
35 mmH2O (345pa)

85%:
32 mmH2O (315pa)

65%:
23 mmH2O (226pa)

* Recommend

M9BA610610290 610×610×290 mm 56.6 CMM
(2000 CFM)
Single
Flange		 M9FA289593290 289×593×290 mm 25.3 CMM
(893 CFM)
M9FA593593292 593×593×290 mm 56.6 CMM
(2000 CFM)
Box
Type		 M9BA305610150 305×610×150 mm 13.0 CMM
(459 CFM)

95%:
10.5 mmH2O (103pa)

85%:
8.9 mmH2O (88pa)

65%:
4.6 mmH2O (45pa)

95%:
27 mmH2O (265pa)

85%:
23 mmH2O (225pa)

65%:
12 mmH2O (120pa)

* Recommend

M9BA610610150 610×610×150 mm 27.5 CMM
(971 CFM)
Single
Flange		 M9FA289593150 289×593×150 mm 12.3 CMM
(434 CFM)
M9FA593593150 593×593×150 mm 27.5 CMM
(971 CFM)

*Special dimension can be customized

Performance Chart

Filter Three-View
